Motor
Motor case/ Precision progressive tool , Precision progressive tool and transfer tool
'Mechanical production to press production'
Press production provide a stable dimension accuracy, concentricity and roundness.
| Stamping product | Motor case, Motor yoke, Motor cover |
|---|---|
| Tool type | Precision transfer tool |
| Material | SPCC, thickness 1.2mm |
| Point | Shape is inserted into the bearing bore |
| Stamping product | Motor case, Motor yoke, Motor cover |
|---|---|
| Tool type | Precision progressive tool |
| Material | SPCC, thickness 2.0mm |
| Point | Crimp in the progressive press tool |
| Stamping product | Motor case, Motor yoke, Motor cover |
|---|---|
| Tool type | Precision progressive press tool |
| Material | SPCC, thickness 0.8mm |
| Point | Arrows indicate the Shimmy trimming part in progressive press tool . Flange part are cut off. |
| Stamping product | Motor case, Motor yoke, Motor cover |
|---|---|
| Tool size | 250×1,000×500mm |
| Material | SPCC, thickness 0.6mm |
| Point | Shape is inserted into the bearing bore |
